Structural map of Eastern Eurasia-PDF

79,00

Structural map of Eastern Eurasia-PDF

2nd edition: August 2008
Equatorial scale: 1/12 500 000
1 sheet: 118 x 84 cm
CCGM-CGMW
Main author : Manuel Pubellier (CNRS-Ecole Normale Supérieure Paris)
Main contributors: N. Chamot-Rooke (CNRS-Ens, F. Ego (Ens), J.C. Guézou (CNRS), E. Konstantinovskaya (INRS-ETE), A. Rabaute (Ens-GeosubSight), J.C. Ringenbach (TOTAL)

Availability: In stock

Secure payment guaranteed

Description

Structural map of Eastern Eurasia-PDF

Scanned version in high resolution .pdf format, sent by download link.

Note: This map is subject to a licence agreement.

This map is also available in digital .pdf format in our catalogue.

Evolution des blocs crustaux et des ceintures orogéniques à travers le temps

La Carte structurale de l’Eurasie orientale-PDF diffère des cartes, géologiques, tectoniques, et de terranes, et met l’accent sur la corrélation des grandes ceintures de l’Eurasie. Les unités représentées ne sont donc pas des terranes tectono-stratigraphiques, mais une individualisation des blocs stables et des prismes sédimentaires et orogéniques. La carte est orientée vers une lisibilité globale des ceintures tectoniques qui ont contribué à la croissance continentale de la partie orientale de l’Eurasie.

Stable blocks and zones represent units of continental crust that have behaved as rigid entities during major orogens and constitute the autochthonous of sedimentary or orogenic prisms. These units are separated by orogenic belts on the map, but do not represent a specific age. Thus, the cores of the main cratons formed during the Precambrian are represented, but also crustal blocks or oceanic plateaus individualised more recently, and responsible for the shortening of the prisms.

Structural map of Eastern Eurasia-PDF

Prismes et orogènes incluent les prismes d’accrétion développés en mer dans des zones de subduction mais également à terre dans les ceintures orogéniques. Ils représentent des produits de subduction indépendamment de la nature – océanique ou continentale – des croûtes impliquées. Ils représentent la plupart du temps des ceintures déformées de sédiments, métamorphosés ou non, chevauchant actuellement des croûtes continentales.

Les prismes orogéniques peuvent également impliquer des lanières crustales de croûte continentale. Dans des zones complexes, surtout dans le début du Phanerozoique, des ceintures orogéniques sont fortement métamorphisées et peuvent être considérées comme « cratonisées ».

Structural map of Eastern Eurasia-PDF
The Rifts have been compiled, generalised and classified by age where possible. Choices had to be made when information was missing, unclear, or contradictory. Many faults have also been reactivated; the colour indicates the age of the dominant event.

The sutures have also been classified chronologically, but the age may vary significantly along them as a result of migration of the docking. In ancient belts, by erosion, they represent the boundary of juxtaposed or overlapped crusts. Their course is approximate and may pass through several alignments of ophiolithic massifs, highlighting either their allochthonous position or the existence of arc/back-arc system closures.

The metamorphic facies are indicated by coloured dots - indicating the dominant facies - so as not to load and obscure the structural information.

Structural map of Eastern Eurasia-PDF
